When a powered walkie high lifter stops lifting smoothly, develops a steering problem, or starts behaving differently during travel, guessing at the failed component can waste both parts and workshop time. This Toyota 00700-CL3WS-RP Master Service Manual gives technicians a focused reference for the 6BWC10, 6BWC15, 6BWC20, 6BWS11, 6BWS15, 6BWS20 and 6BWR15 electric walkie high lifter trucks. The manual is dated August 1, 2002 and identifies an effective serial reference beginning at 6BWC10-20001 and up.

Machine Information

Machine Detail	Information
Manufacturer	Toyota
Equipment Type	Electric Walkie High Lifter Trucks
6BWC Models	6BWC10, 6BWC15, 6BWC20
6BWS Models	6BWS11, 6BWS15, 6BWS20
6BWR Model	6BWR15
Series Coverage	6BWC10-20, 6BWS11-20 & 6BWR15
Effective Serial Reference	6BWC10-20001 and up

Manual Specifications

Manual Detail	Specification
Publication Number	00700-CL3WS-RP
Document Type	Master Service Manual
Format	PDF
Language	English
Issue Date	August 1, 2002
Core Coverage	Chassis, motors, transmission, braking, steering, electrical, hydraulic/pneumatic and lifting mast/cylinders

What Is Actually Inside the Manual?

This Toyota manual is unusually useful for troubleshooting because it does not stop at general service instructions. Its technical structure covers the machine from the frame and drive components through the electrical controls and into the hydraulic lifting equipment. Toyota classifies the covered systems into chassis, motors, drive gear/transmission, brake/wheel system, steering system, electrical system, hydraulic/pneumatic system, and lifting mast/cylinders.

Repair Area	Relevant Information
Motor system	Pump motor and drive motor service, brush replacement, component inspection and repair
Transmission	System description, troubleshooting, removal, installation and transmission assembly work
Brake & wheel system	Parking brake, brake adjustment, brake-shoe work, drive wheel, swivel/caster and load-wheel service
Steering & controls	Steering arm/wheel, tiller assembly, control handle, direction switches, raise/lower switches and potentiometer
Electrical functions	Operating logic, adjustable settings, switches, travel requests and reversing/motor-braking functions
Lifting equipment	Hydraulic/pneumatic systems and operating-function lifting mast/cylinder information

Where This Manual Can Save Workshop Time

A good example is a truck that moves but does not lift correctly. The fault may not be immediately obvious, so the technician can use the lifting, hydraulic and control information rather than starting with unrelated drive components. Likewise, a truck that travels in one direction but behaves incorrectly during reversing can be investigated through the documented electrical functions, direction controls and motor-braking operation.

The manual's contents specifically include pump-motor and drive-motor troubleshooting, transmission troubleshooting, caster adjustment, load wheels, steering controls, direction-control switches, raise/lower and horn switches, potentiometer service and electrical operating functions.

Electrical and Control-System Detail

This is one of the strongest areas of the document for technicians working on an older electric walkie truck. The electrical-functions section goes beyond simply showing components. It describes operating conditions involving the key switch, operating arm, brake switch, travel request, fork orientation and reversing/motor-braking direction changes. The manual also includes service information for the control-handle head, direction switches, raise/lower/horn switches, potentiometer and reverser assembly.

Drive, Brake and Running Gear

For trucks with a travel, braking or wheel-end complaint, the manual provides a much more useful path than a generic electric-forklift guide. The documented material covers the transmission, parking brake, brake adjustment, brake-shoe removal and installation, drive wheel, support/swivel wheel, caster adjustment, load wheels and caster assembly.

That makes the manual relevant to problems such as abnormal travel, braking concerns, wheel wear, caster instability, steering response and transmission-related noise.

Why the Exact Model Range Matters

The supplied filename uses shorthand such as 6BWC0-20 and 6BWS-20, but the actual Toyota manual identifies the models as 6BWC10, 6BWC15, 6BWC20, 6BWS11, 6BWS15, 6BWS20 and 6BWR15. Toyota labels the document a Master Service Manual, and the model coding confirms that the intermediate models should not be omitted when describing the product.

Check Your Truck Before Ordering

The cover identifies an effective serial reference of 6BWC10-20001 and up. It is therefore worth checking the identification/data plate on the truck before purchase, particularly where an older 6BWC, 6BWS or 6BWR machine has been modified or where another production range is being considered.

PDF Features

• English Toyota Master Service Manual in PDF format
• Model-specific information for seven covered truck models
• Electrical, mechanical and hydraulic service information
• Technical illustrations and component procedures
• Searchable and zoomable digital reference
• Printable pages for workshop use

Frequently Asked Questions

Which Toyota models are covered by 00700-CL3WS-RP?

The manual covers 6BWC10, 6BWC15, 6BWC20, 6BWS11, 6BWS15, 6BWS20 and 6BWR15.

What type of Toyota equipment is this manual for?

It is for Toyota Electric Walkie High Lifter Trucks.

Does the manual cover electric motors?

Yes. The contents include both pump-motor and drive-motor service, including troubleshooting, removal, installation, brush replacement and component repair.

Can I use it for transmission or travel problems?

Yes. A dedicated transmission section includes system description, troubleshooting, removal, installation and assembly information.

Does it cover the steering and tiller controls?

Yes. The manual includes steering-arm/wheel and tiller-arm information, the control-handle head, direction switches, raise/lower and horn switches, potentiometer and reverser assembly.

Is hydraulic and lifting information included?

Yes. Toyota categorizes hydraulic/pneumatic systems and operating-function lifting mast/cylinders as dedicated technical groups within the manual.

What publication number should I search for?

The manual is identified by Toyota part/publication number 00700-CL3WS-RP.

What date is shown on the manual?

The cover is dated August 1, 2002.

What serial information is shown?

The cover identifies an effective serial reference of 6BWC10-20001 and up.

Is this an operator manual?

No. It is a Master Service Manual intended for technical servicing, troubleshooting, component repair and workshop reference.
