Repairing a high-capacity Toyota 5-Series forklift requires more than basic operating information. This CE005-1 Service & Repair Manual brings together the factory workshop procedures for the 5FG33, 5FG35, 5FD33, 5FD35, 5FD40, 5FD45, 5FGE35, 5FDE35 and 5FDA50 forklifts, covering the major mechanical, hydraulic, steering, braking and material-handling systems used on these machines.

The manual is especially useful when you need to move from a symptom or component problem to the correct repair procedure. It includes detailed service information for the engine, clutch, torque converter, transmission and differential, axles, steering, brakes, mast, lift cylinders, oil pump and oil control valve.

Exact Toyota Models Covered

Factory Repair Coverage

The primary CE005 section is organized as a complete workshop reference rather than a simple owner's guide. Its section index includes the following repair areas:

• General — vehicle information, service precautions, specifications and inspection reference.
• Engine — engine-related removal, inspection and service procedures.
• Clutch & Torque Converter — clutch components and torque-converter service.
• Transmission & Differential — driveline inspection, dismantling and repair information.
• Front & Rear Axles — axle and related component procedures.
• Steering — steering-system service, including steering-knuckle related work.
• Brake — brake-system inspection and repair information.
• Body — chassis and body-related service procedures.
• Material Handling System — lifting-system components and service information.
• Mast & Cylinder — mast assemblies, lift cylinders and associated components.
• Oil Pump & Oil Control Valve — hydraulic-system troubleshooting and repair reference.
• Appendix — supporting technical information and workshop references.

Useful Hydraulic and Material-Handling Information

For technicians working on lift performance, hydraulic drift or mast-related problems, the manual includes information covering the mast, cylinders, hydraulic piping, oil pump and oil control valve. The documented inspection material includes checks related to cylinder condition, natural drop, forward tilt, lifting speed, oil leakage, hydraulic piping and relief-pressure measurement.

Engine and Powertrain Service

The powertrain portion of the manual goes beyond basic component identification. It provides workshop procedures covering the engine, clutch, torque converter, transmission, differential and propeller-shaft/driveline-related assemblies. Toyota also references separate engine repair manuals for the applicable power units, including the 3F, 1FZ and 11Z/12Z engine families.

CE005 and CE014 Combined Reference

An important detail about this manual is that the CE005-1 document combines Part I based on Repair Manual CE005 with Part II based on Supplement CE014. Part I covers service procedures for models produced from August 1988, while Part II addresses forklifts subject to the September 1994 minor change. Toyota advises using both parts when servicing vehicles produced after that minor change.

Why This Manual Is Useful in the Workshop

When working on an older 5-Series Toyota forklift, the biggest challenge is often finding the correct procedure for the particular machine configuration. This manual brings the relevant model family into one reference, helping technicians work through mechanical repairs, hydraulic faults, steering issues, brake work and mast-related service without relying solely on general forklift information.

It is suited to forklift mechanics, service technicians, repair workshops, fleet maintenance teams and experienced equipment owners who need detailed technical service information for these Toyota models.

PDF Manual Features

• Language: English
• Format: PDF
• Instant digital access
• Searchable workshop information
• Printable repair reference
• Zoomable service illustrations and diagrams
• Convenient for workshop and field-service use

Frequently Asked Questions

Which Toyota forklifts are covered by CE005-1?

The documented coverage includes 5FG33, 5FG35, 5FD33, 5FD35, 5FD40, 5FD45, 5FGE35, 5FDE35 and 5FDA50.

What is the actual Toyota publication number?

The complete combined manual is identified as CE005-1, incorporating the original CE005 repair-manual material and CE014 supplement material.

Does it include the 5FD40 and 5FD45?

Yes. The 5FD portion extends through 5FD33, 5FD35, 5FD40 and 5FD45.

Does the manual cover hydraulic and mast repairs?

Yes. Dedicated sections cover the material handling system, mast, cylinders, oil pump, oil control valve and hydraulic piping.

What is the difference between CE005 and CE014 in this manual?

CE005 forms Part I for the original service procedures, while CE014 is the supplement forming Part II for the September 1994 minor-change models.

Is this an operator manual?

No. This is a technical repair and service manual intended for workshop diagnosis, component service, adjustment, dismantling and reassembly.
