New Holland 216 Unitized Rake Basket Rake Pdf Repair Service Manual (p. Nb. 87049456)

New Holland 216 Unitized Basket Rake PDF Repair Service Manual (Publication No. 87049456)

Covering up to 27 feet (8.2 m) in a single pass, the New Holland 216 Unitized Basket Rake was designed to help hay producers reduce field time while producing clean, uniform windrows. Unlike conventional pull-type rakes, the 216 combines two hydraulically driven rake baskets on a single heavy-duty frame, allowing operators to merge multiple windrows efficiently while maintaining consistent crop flow and minimizing leaf loss in delicate forage crops.

Because both rake baskets, hydraulic drives, suspension links and tine assemblies operate continuously across uneven terrain, accurate servicing is essential for dependable performance. This OEM Factory Repair Service Manual (Publication No. 87049456) provides dealership workshop procedures for inspection, adjustment, diagnostics and complete overhaul, enabling technicians to restore factory operating specifications while extending machine service life.

Machine Highlights

The 216 Unitized Rake was developed for medium and large hay operations where field efficiency is critical. Its hydraulic basket drive eliminates traditional ground-drive mechanisms, while the unitized frame keeps both baskets synchronized through turns and varying terrain. Adjustable basket tilt allows operators to produce either fluffy windrows for rapid drying or tighter windrows for baling, depending on crop conditions.

Machine Information

Factory Workshop Coverage

Professional Workshop Procedures

• Synchronize both hydraulic rake baskets for even crop delivery.
• Adjust basket tilt to produce either loose or dense windrows.
• Replace damaged Dyna-tines while maintaining correct tine alignment.
• Inspect spider bearings and basket shafts for excessive wear.
• Service hydraulic motors and verify proper reel speed.
• Repair swing arm pivots and suspension linkage assemblies.
• Inspect wheel hubs and transport axle components before road transport.
• Test hydraulic pressure and flow to ensure consistent basket operation.
• Use exploded factory illustrations for accurate component assembly.
• Apply OEM torque specifications during all structural and hydraulic repairs.
• Verify basket overlap, working width and windrow consistency after servicing.
• Perform complete field operational testing before returning the rake to production.

Manual Specifications

Frequently Asked Questions

Which machine is covered by this repair manual?

This OEM workshop manual covers the New Holland 216 Unitized Basket Rake (Publication No. 87049456).

Does the manual include hydraulic basket drive repairs?

Yes. It provides complete factory procedures for servicing hydraulic motors, control valves, hoses, pressure testing and basket drive diagnostics.

Are tine bars and basket assemblies covered?

Yes. The manual explains basket rebuilding, tine replacement, spider bearing servicing, stripper bar adjustment and complete basket alignment procedures.

Does the manual include transport and suspension adjustments?

Yes. Frame alignment, swing arm pivots, suspension linkage, transport axle assemblies and hydraulic folding functions are covered.

Who should use this workshop manual?

This manual is intended for New Holland dealership technicians, hay equipment repair shops, commercial forage producers and experienced mechanics servicing the 216 Unitized Basket Rake.
