The Compact designation on the D024 Fortis is not a capacity description — the S135FT and S155FT are rated at 13,500 lb and 15,500 lb, which is unambiguously heavy industrial territory. Compact here refers to the chassis design: a shorter wheelbase and reduced overall footprint relative to standard heavy-capacity counterbalance platforms, allowing the D024 to operate in facility layouts and aisle configurations that a full-size machine at equivalent capacity cannot access. That design difference has direct service implications. Compact chassis geometry affects the disassembly and access sequences for the transmission, drive axle, and hydraulic components — procedures written for a standard-footprint S135FT platform do not map accurately onto the D024 physical layout. The Hyster D024 Fortis Repair Service Manual documents procedures specific to this chassis configuration, not adapted from a larger platform sharing the same model names.

The D024 is also the fourth generation in the S135FT and S155FT series alongside the E024, F024, and G024. Each carries the Fortis name on some variants, different tyre configurations on others, and generation-specific hydraulic circuits and electrical layouts throughout. The series code on the data plate is the only reliable way to confirm which generation is in front of you. D024 means this document — not the E024, F024, or G024 publication covering the same model names under different build standards.

Manual Technical Specifications

Purchasing From Manualskart

Manualskart lists the D024 as a separate publication from the E024, F024, and G024 — all four generations share the S135FT and S155FT model names but are indexed individually by series code. Searching D024 returns the Fortis compact chassis generation document without requiring cross-referencing against multiple combined listings.

• Immediate download after purchase — no processing delay
• Single purchase, permanent access with no renewal fees
• Full-text searchable PDF — torque values, pressure specifications, and wiring references are keyword-findable
• Printable by section for workshop bench use
• 30-day refund if the series code does not match your machine
• SSL-secured checkout via PayPal or card

Why This Manual Matters for D024 Service

• The D024 compact chassis geometry directly affects transmission removal sequencing, drive axle access, and hydraulic component clearances — procedures from any standard-footprint S135FT or S155FT generation document do not map correctly onto the D024 physical layout
• Four generations now share the S135FT and S155FT model names — D024, E024, F024, and G024 — each with its own hydraulic circuit configuration and electrical layout; the series code is the only reliable identifier and the D024 build standard is specific to this generation only
• At 13,500 to 15,500 lb on a compact chassis, hydraulic relief values and brake specifications carry direct consequence for both equipment integrity and floor safety — factory figures specific to the D024 are the only valid reference, not values approximated from adjacent generations
• The 2,000 lb capacity step between S135FT and S155FT produces distinct clutch circuit pressure values, brake drum wear limits, and drivetrain tolerances — both sets are documented separately so each machine is serviced to its own rated standard
• Stall test and clutch pressure check procedures are positioned as diagnostic steps before transmission disassembly — identifying whether a fault lies in the torque converter, clutch circuit, or control valve before the compact chassis layout makes a full transmission strip necessary

Systems and Repair Coverage

Complete diagnostic, disassembly, and rebuild procedures for both D024 Fortis variants — with disassembly sequences reflecting the compact chassis layout throughout:

• Engine Overhaul and Fuel System: Cylinder bore and wear measurement, valve clearance per variant, cylinder head surface flatness and valve seat recession, head bolt torque sequence — LPG regulator and mixer calibration documented to D024 Fortis installation specification, diesel injection pump static and dynamic timing with nozzle return rate testing and fuel bleed sequence, each configuration covered with fully independent procedures
• Hydraulic Mast and Lift Circuit: Mast channel wear and roller clearance adjustment, lift cylinder bore condition and drift test under working load, seal kit replacement, tilt cylinder rod seal service, main relief valve calibration with S135FT and S155FT values separately identified, load-hold valve leak test, and hydraulic pump output pressure and flow testing — component access sequencing reflects D024 compact chassis clearances
• Powershift Transmission and Torque Converter: Stall test and rpm deviation interpretation, forward and reverse clutch circuit pressure testing per capacity variant, clutch pack disc and plate measurement, pack clearance specification, transmission removal and disassembly sequence specific to D024 compact chassis layout, modulation valve spool inspection, and fault diagnosis for engagement hesitation, direction change harshness, and converter temperature faults
• Drive Axle and Differential: Shaft spline condition assessment, ring and pinion backlash and mesh geometry setting, carrier bearing preload, axle housing weld stress inspection, hub bearing end-float specification, and seal replacement — access procedure reflecting compact chassis axle positioning, S155FT load tolerances identified where higher capacity produces values distinct from S135FT
• Electrical System and Safety Interlock Diagnosis: Alternator output and starter draw testing, hydraulic solenoid coil resistance per D024 Fortis specification, seat switch and directional lever interlock tested as individual component checks, parking brake circuit continuity, engine protection sender test values, and instrument and warning circuit fault tracing
• Steering Axle and Brake Service: King pin bore wear limit and replacement threshold, toe-in specification after axle rebuild, hub bearing preload adjustment, brake drum wear limit and lining minimum documented per capacity variant, wheel cylinder inspection and bleed sequence, pedal travel adjustment, and parking brake holding force test at rated machine weight

Download the Hyster Fortis S135FT S155FT D024 Service Manual PDF

The compact chassis changes how this machine is accessed — get the procedures that reflect the actual D024 layout rather than a standard-footprint approximation. The complete Hyster Fortis S135FT S155FT D024 factory repair manual is available immediately at Manualskart.com. Find all four S135FT and S155FT generations alongside the full Hyster Fortis range in the Hyster Service Manual Collection. This Hyster D024 service manual PDF is an 840+ page compact chassis document with generation-specific procedures, capacity-variant specifications, and D024 Fortis hydraulic and electrical values that do not carry over from any other series.
